(2023) PASS NSE7_LED-7.0 Exam Free Practice Test with 100% Accurate Answers

NSE7_LED-7.0 dumps Free Test Engine Verified By It Certified Experts

The Fortinet NSE 7 – LAN Edge 7.0 certification is intended for network security professionals who are responsible for securing LAN edge environments in medium to large organizations. Candidates who pass the exam will have demonstrated their proficiency in designing and implementing secure LAN edge solutions using Fortinet technologies. Fortinet NSE 7 – LAN Edge 7.0 certification is recognized globally and is a valuable credential for network security professionals looking to advance their careers.

To pass the certification exam, candidates must demonstrate a deep understanding of LAN Edge technologies and Fortinet products, as well as the ability to design, configure, and troubleshoot complex network solutions. Successful candidates will receive the Fortinet NSE7_LED-7.0 certification, which is recognized globally as a mark of excellence in LAN Edge and network security knowledge and skills.

NO.13 Refer to the exhibit.

Examine the FortiManager information shown in the exhibit
Which two statements about the FortiManager status are true” (Choose two)

FortiSwitch manager is working in per-device management mode

FortiSwitch is not authorized

FortiSwitch manager is working in central management mode

FortiSwitch is authorized and offline

Explanation
According to the FortiManager Administration Guide, “Central management mode allows you to manage all FortiSwitch devices from a single interface on the FortiManager device.” Therefore, option C is true because the exhibit shows that the FortiSwitch manager is enabled and the FortiSwitch device is managed by the FortiManager device. Option D is also true because the exhibit shows that the FortiSwitch device status is offline, which means that it is not reachable by the FortiManager device, but it is authorized, which means that it has been added to the FortiManager device. Option A is false because per-device management mode allows you to manage each FortiSwitch device individually from its own web-based manager or CLI, which is not the case in the exhibit. Option B is false because the FortiSwitch device is authorized, as explained above.

NO.14 When you configure a FortiAP wireless interface for auto TX power control which statement describes how it configures its transmission power”?

Every 30 seconds the AP will measure the signal strength of the AP using the client The AP will adjust its signal strength up or down until the AP signal is detected at -70 dBm

Every 30 seconds FortiGate measures the signal strength of adjacent AP interfaces It will adjust its own AP power to match the adjacent AP signal strength

Every 30 seconds FortiGate measures the signal strength of adjacent FortiAP interfaces It will adjust the adjacent AP power to be detectable at -70 dBm

Every 30 seconds FortiGate measures the signal strength of the weakest associated client The AP will then configure its radio power to match the detected signal strength of the client

Explanation
According to the FortiAP Configuration Guide1, “Auto TX power control allows the AP to adjust its transmit power based on the signal strength of the client. The AP will measure the signal strength of the client every 30 seconds and adjust its transmit power up or down until the client signal is detected at -70 dBm.” Therefore, option A is true because it describes how the FortiAP wireless interface configures its transmission power when auto TX power control is enabled. Option B is false because FortiGate does not measure the signal strength of adjacent AP interfaces, but rather the FortiAP does. Option C is false because FortiGate does not adjust the adjacent AP power, but rather the FortiAP adjusts its own power. Option D is false becauseFortiGate does not measure the signal strength of the weakest associated client, but rather the FortiAP does.

NO.15 Refer to the exhibit.

Examine the LDAP server configuration shown in the exhibit Note that the Username setting has been expanded to display Its full content On the Windows AD server 10.0.1.10, the administrator used dsquery. which returned the following output:

According to the output which FortiGate LDAP setting is configured incorrectly”

Common Name Identifier

Bind Type

Distinguished Name

Username

Explanation
According to the exhibits, the LDAP server configuration on FortiGate has the Distinguished Name set to
“dc=training,dc=lab”. However, according to the output of the dsquery command on the Windows AD server, the Distinguished Name of the domain should be “dc=trainingAD,dc=training,dc=lab”. Therefore, option C is true because the Distinguished Name on FortiGate is configured incorrectly and does not match the actual Distinguished Name of the domain. Option A is false because the Common Name Identifier on FortiGate is configured correctly as “cn”. Option B is false because the Bind Type on FortiGate is configured correctly as
“Regular”. Option D is false because the Username on FortiGate is configured correctly as
“cn=admin,cn=users,dc=trainingAD,dc=training,dc=lab”.

NO.16 Refer to the exhibit

Examine the FortiGate RSSO configuration shown in the exhibit
FortiGate is configured to receive RADIUS accounting messages on port3 to authenticate RSSO users The users are located behind port3 and the internet link is connected to port1 FortiGate is processing incoming RADIUS accounting messages successfully and RSSO users are getting associated with the RSSO Group user group However all the users are able to access the internet, and the administrator wants to restrict internet access to RSSO users only Which configuration change should the administrator make to fix the problem?

Change the RADIUS Attribute Value selling to match the name of the RADIUS attribute containing the group membership information of the RSSO users

Add RSSO Group to the firewall policy

Enable Security Fabric Connection on port3

Create a second firewall policy from port3 lo port1 and select the target destination subnets

Explanation
According to the exhibit, the firewall policy from port3 to port1 has no user group specified, which means that it allows all users to access the internet. Therefore, option B is true because adding RSSO Group to the firewall policy will restrict internet access to RSSO users only. Option A is false because changing the RADIUS Attribute Value setting will not affect the firewall policy, but rather the RSSO user group membership. Option C is false because enabling Security Fabric Connection on port3 will not affect the firewall policy, but rather the communication between FortiGate and other Security Fabric devices. Option D is false because creating a second firewall policy from port3 to port1 will not affect the existing firewall policy, but rather create a redundant or conflicting policy.

NO.17 You are investigating a report of poor wireless performance in a network that you manage. The issue is related to an AP interface in the 5 GHz range You are monitoring the channel utilization over time.
What is the recommended maximum utilization value that an interface should not exceed?

85%

95%

75%

65%

Explanation
According to the FortiAP Configuration Guide, “Channel utilization measures how busy a channel is over a given period of time. It includes both Wi-Fi and non-Wi-Fi interference sources. A high channel utilization indicates a congested channel and can result in poor wireless performance. The recommended maximum utilization value that an interface should not exceed is 65%.” Therefore, option D is true because it gives the recommended maximum utilization value for an interface in the 5 GHz range. Options A, B, and C are false because they give higher utilization values that can cause poor wireless performance.
https://docs.fortinet.com/document/fortiap/7.0.0/configuration-guide/734537/wireless-radio-settings#channel-uti

NO.18

Wireless guest users are unable to authenticate because they are getting a certificate error while loading the captive portal login page.This URL string is the HTTPS POST URL guest wireless users see when attempting to access the network using the web browser

Which two settings are the likely causes of the issue? (Choose two.)

The external server FQDN is incorrect

The wireless user’s browser is missing a CA certificate

The FortiGate authentication interface address is using HTTPS

The user address is not in DDNS form

Explanation
According to the exhibit, the wireless guest users are getting a certificate error while loading the captive portal login page. This means that the browser cannot verify the identity of the server that is hosting the login page.
Therefore, option A is true because the external server FQDN is incorrect, which means that it does not match the common name or subject alternative name of the server certificate. Option B is also true because the wireless user’s browser is missing a CA certificate, which means that it does not have the root or intermediate certificate that issued the server certificate. Option C is false because the FortiGate authentication interface address is using HTTPS, which is a secure protocol that encrypts the communication between the browser and the server. Option D is false because the user address is not in DDNS form, which is not related to the certificate error.

NO.19 Refer to the exhibit.

Examine the debug output shown in the exhibit
Which two statements about the RADIUS debug output are true” (Choose two)

The user student belongs to the SSLVPN group

User authentication failed

The RADIUS server sent a vendor-specific attribute in the RADIUS response

User authentication succeeded using MSCHAP

Explanation
According to the exhibit, the debug output shows a RADIUS debug output from FortiGate. The output shows that FortiGate sent a RADIUS Access-Request packet to FortiAuthenticator with the username student and received a RADIUS Access-Accept packet from FortiAuthenticator with a Class attribute containing SSLVPN.
Therefore, option A is true because it indicates that the user student belongs to the SSLVPN group on FortiAuthenticator. The output also shows that FortiGate used MSCHAP as the authentication method and received a MS-MPPE-Send-Key and a MS-MPPE-Recv-Key from FortiAuthenticator. Therefore, option D is true because it indicates that user authentication succeeded using MSCHAP. Option B is false because user authentication did not fail, but rather succeeded. Option C is false because FortiAuthenticator did not send a vendor-specific attribute in the RADIUS response, but rather standard attributes defined by RFCs.

NO.20 Where can FortiGate learn the FortiManager IP address or FQDN for zero-touch provisioning’?

From an LDAP server using a simple bind operation

From a TFTP server

From a DHCP server using options 240 and 241

From a DNS server using A or AAAA records

Explanation
According to the FortiGate Administration Guide, “FortiGate can learn the FortiManager IP address or FQDN for zero-touch provisioning from a DNS server using A or AAAA records. The DNS server must be configured to resolve the hostname fortimanager.fortinet.com to the IP address or FQDN of the FortiManager device.” Therefore, option D is true because it describes the method for FortiGate to learn the FortiManager IP address or FQDN for zero-touch provisioning. Option A is false because LDAP is not used for zero-touch provisioning. Option B is false because TFTP is not used for zero-touch provisioning. Option C is false because DHCP options 240 and 241 are not used for zero-touch provisioning.

NO.21 Exhibit.

Exhibit.

Refer to the exhibits
In the wireless configuration shown in the exhibits, an AP is deployed in a remote site and has a wireless network (VAP) called Corporate deployed to it The network is a tunneled network however clients connecting to a wireless network require access to a local printer Clients are trying to print to a printer on the remote site but are unable to do so Which configuration change is required to allow clients connected to the Corporate SSID to print locally?

Configure split-tunneling in the vap configuration

Configure split-tunneling in the wtp-profile configuration

Disable the Block Intra-SSID Traffic (intra-vap-privacy) setting on the SSID (VAP) profile

Configure the printer as a wireless client on the Corporate wireless network

Explanation
According to the Fortinet documentation1, “Split tunneling allows you to specify which traffic is tunneled to the FortiGate and which traffic is sent directly to the Internet. This can improve performance and reduce bandwidth usage.” Therefore, by configuring split-tunneling in the vap configuration, you can allow the clients connected to the Corporate SSID to access both the corporate network and the local printer. Option B is incorrect because split-tunneling is configured at the vap level, not the wtp-profile level. Option C is incorrect because blocking intra-SSID traffic prevents wireless clients on the same SSID from communicating with each other, which is not related to accessing a local printer. Option D is unnecessary and impractical because the printer does not need to be a wireless client on the Corporate wireless network to be accessible by the clients.

NO.22 An administrator has configured an SSID in bridge mode for corporate employees All APs are online and provisioned using default AP profiles Employees are unable to locate the SSID to conned Which two configurations can the administrator verify? (Choose two)

Verify that the broadcast SSID option is enabled in the SSID configuration

Verify that the Block Intra-SSID Traffic (intra-vap-privacy) option in the SSID configuration is disabled

Verify that the SSID to an AP group that should be broadcasting the SSID is applied

Verify that the SSID is manually applied on AP profiles for both 2 4 GHz and 5 GHz radios

Explanation
According to the FortiAP Configuration Guide1, “To enable the SSID, you must select at least one channel for the radio. If no channels are selected, the SSID will not be enabled. You must also enable Broadcast SSID.” Therefore, option A is true because the broadcast SSID option allows the SSID to be visible to wireless clients.
Option C is also true because the SSID must be applied to an AP group that contains the APs that should be broadcasting the SSID. According to the same guide1, “You can create AP groups and assign them to different locations or departments. You can then apply different settings, such as SSIDs, to each group.” Option B is false because blocking intra-SSID traffic prevents wireless clients on the same SSID from communicating with each other, which is not related to broadcasting the SSID. Option D is false because the SSID can be applied to an AP group or a global profile, which will automatically apply to all APs, without manually configuring each AP profile.

NO.23 Which two statements about the guest portal on FortiAuthenticator are true? (Choose two.)

Each remote user on FortiAuthenticator can sponsor up to 10 guest accounts

Administrators must approve all guest accounts before they can be used

The guest portal provides pre and post-log in services

Administrators can use one or more incoming parameters to configure a mapping rule for the guest portal

Explanation
According to the FortiAuthenticator Administration Guide2, “The guest portal provides pre and post-log in services for users (such as password reset and token registration abilities), and rules and replacement messages can be configured.” Therefore, option C is true. The same guide also states that “Administrators can use one or more incoming parameters to configure a mapping rule for the guest portal.” Therefore, option D is true.
Option A is false because remote users can sponsor any number of guest accounts, as long as they do not exceed the maximum number of guest accounts allowed by the license. Option B is false because administrators can choose to approve or reject guest accounts, or enable auto-approval.

NO.24 Refer to the exhibit.

Examine the RADIUS server configuration shown in the exhibit
An administrator has configured a RADIUS server on FortiGate that points to FortiAuthenticator FortiAuthenticator is acting as an authentication proxy and is configured to relay all authentication requests to a remote Windows AD server using LDAP While testing the configuration the administrator noticed that the diagnosetest authserver command worked with PAP, however authentication requests failed when using MSCHAP2 Which two solutions can the administrator implement to get MSCHAP2 authentication to work” (Choose two.)

On FortiAuthenticator enable Windows Active Directory Domain Authentication to add FortiAuthenticator to the Windows domain

On FortiGate configure the NAS IP setting on the RADIUS
server

On FortiAuthenticator change the back-end authentication server from LDAP to RADIUS

On FortiGate update the Secret setting on the RADIUS server

Explanation
According to the exhibit, the RADIUS server configuration on FortiGate points to FortiAuthenticator, which is acting as an authentication proxy and is configured to relay all authentication requests to a remote Windows AD server using LDAP. However, LDAP does not support MSCHAP2 authentication, which is required for RADIUS. Therefore, option A is true because on FortiAuthenticator, enabling Windows Active Directory Domain Authentication will add FortiAuthenticator to the Windows domain and allow it to use MSCHAP2 authentication with the AD server. Option C is also true because on FortiAuthenticator, changing the back-end authentication server from LDAP to RADIUS will allow it to use MSCHAP2 authentication with the AD server. Option B is false because on FortiGate, configuring the NAS IP setting on the RADIUS server will not affect the MSCHAP2 authentication, but rather the source IP address of the RADIUS packets. Option D is false because on FortiGate, updating the Secret setting on the RADIUS server will not affect the MSCHAP2 authentication, but rather the shared secret between FortiGate and FortiAuthenticator.

NO.25 What is the purpose of enabling Windows Active Directory Domain Authentication on FortiAuthenticator?

It enables FortiAuthenticator to use Windows administrator credentials to perform an LDAP lookup for a user search

It enables FortiAuthenticator to use a Windows CA certificate when authenticating RADIUS users

It enables FortiAuthenticator to import users from Windows AD

It enables FortiAuthenticator to register itself as a Windows trusted device to proxy authentication using Kerberos

Explanation
According to the FortiAuthenticator Administration Guide2, “Windows Active Directory domain authentication enables FortiAuthenticator to join a Windows Active Directory domain as a machine entity and proxy authentication requests using Kerberos.” Therefore, option D is true because it describes the purpose of enabling Windows Active Directory domain authentication on FortiAuthenticator. Option A is false because FortiAuthenticator does not need Windows administrator credentials to perform an LDAP lookup for a user search. Option B is false because FortiAuthenticator does not use a Windows CA certificate when authenticating RADIUS users, but rather its own CA certificate. Option C is false because FortiAuthenticator does not import users from Windows AD, but rather synchronizes them using LDAP or FSSO.

NO.26 Refer to the exhibit

A device connected to port2 on FortiSwitch cannot access the network The port is assigned a security policy to enforce 802 1X authentication While troubleshooting the issue, the administrator obtains the debug output shown in the exhibit Which two scenarios are likely to cause this issue? (Choose two.)

The device is not configured for 802 IX authentication.

The device has been quarantined for 3600 seconds.

The device has been assigned the guest VLAN

The device does not support 802 1X authentication

Explanation
According to the exhibit, the debug output shows that the device connected to port2 on FortiSwitch is sending an EAPOL-Start message, which is the first step of the 802.1X authentication process. However, the output also shows that the device is not sending any EAP-Response messages, which are required to complete the authentication process. Therefore, option A is true because the device is not configured for 802.1X authentication, which means that it does not have the correct credentials or settings to authenticate with the RADIUS server. Option D is also true because the device does not support 802.1X authentication, which means that it does not have the capability or software to perform 802.1X authentication. Option B is false because the device has not been quarantined for 3600 seconds, but rather has a session timeout of 3600 seconds, which is the default value for 802.1X sessions. Option C is false because the device has not been assigned the guest VLAN, but rather has been assigned the default VLAN, which is VLAN 1.

NO.27 Refer to the exhibit

Examine the sections of the configuration shown in the output
What action will FortiGate take when verifying the student certificate through OCSP?

Reject the student certificate if the OCSP server replies that the student certificate status is unknown

Not verify the OCSP server certificate

Use the OCSP URL included in the student certificate to verify the student certificate

Consider the student certificate status as valid if the OCSP server is unreachable

Explanation
According to the exhibit, the FortiGate configuration has ocsp-status enabled and ocsp-option set to certificate.
This means that FortiGate will use OCSP to verify the revocation status of certificates presented by clients. According to the FortiGate Administration Guide2, “If you select certificate, FortiGate uses an OCSP URL included in a certificate to verify that certificate.” Therefore, option C is true because it describes what action FortiGate will take when verifying the student certificate through OCSP. Option A is false because FortiGate will not reject the student certificate if the OCSP server replies that the student certificate status is unknown, but rather accept it as valid. Option B is false because FortiGate will verify the OCSPserver certificate by default, unless strict-ocsp-check is disabled. Option D is false because FortiGate will not consider the student certificate status as valid if the OCSP server is unreachable, but rather reject it as invalid.

NO.28 Refer to the exhibit.

Examine the network diagram and packet capture shown in the exhibit
The packet capture was taken between FortiGate and FortiAuthenticator and shows a RADIUS Access-Request packet sent by FortiSwitch to FortiAuthenticator through FortiGate Why does the User-Name attribute in the RADIUS Access-Request packet contain the client MAC address?

The client is performing AD machine authentication

FortiSwitch is authenticating the client using MAC authentication bypass

The client is performing user authentication

FortiSwitch is sending a RADIUS accounting message to FortiAuthenticator

Explanation
According to the exhibit, the User-Name attribute in the RADIUS Access-Request packet contains the client MAC address of 00:0c:29:6a:2b:3d. This indicates that FortiSwitch is authenticating the client using MAC authentication bypass (MAB), which is a method of authenticating devices that do not support 802.1X by using their MAC address as the username and password. Therefore, option B is true because it explains why the User-Name attribute contains the client MAC address. Option A is false because AD machine authentication uses a computer account name and password, not a MAC address. Option C is false because user authentication uses a user name and password, not a MAC address. Option D is false because FortiSwitch is sending a RADIUS Access-Request message to FortiAuthenticator, not a RADIUS accounting message.
